VMS 750-2 vacuum lifter
Self-priming vacuum lifter VMS 750-2 of 750 kg with 2 suction cups of Ø 400 mm, for sheet metal and slabs up to 3,000 × 1,500 mm. Same geometry as the two-cup 600 kg version, but a reinforced structure: 130 kg of its own weight to carry 750 kg on just two grip points. The vacuum is created by the movement of the hoist itself: lower the hook and the vacuum lifter grips, set the load down and the grip releases. No power, no compressed air and no batteries to recharge are needed, and release cannot happen while the piece is suspended. Materials: steel, stainless steel, aluminium, glass, plastic, stone and wood with a closed, sealed surface.
Minimum workpiece size 850 × 450 mm, minimum thickness 2 mm on steel, minimum load 10 kg. Own weight 130 kg. This configuration has no shut-off valves: every cup must rest on the workpiece.
| Rated capacity | 750 kg |
| Suction cups | 2 × Ø 400 mm |
| Maximum sheet metal size | 3,000 × 1,500 mm |
| Minimum size | 850 × 450 mm |
| Minimum thickness | 2 mm on steel |
| Minimum load | 10 kg |
| Own weight | 130 kg |
| Shut-off valves | no |
| Power supply | none — self-priming vacuum |
Coming to the price list: this product is just entering the Vacuum Lifters range. Ask for availability, lead time and price: we reply the same day with the configuration that suits your material.
