Dismountable 12-pad vacuum lifter for large-format sheets

Dismountable 12-pad vacuum lifter for large-format sheets
Vacuum lifters

The dismountable 12-pad vacuum lifter is designed for large-format sheets that are lifted rarely or in different places: the frame breaks down into light elements, is transported and reassembled on the sheet format, with twelve pads that share the load and keep the thin plate flat. List price €4,200 + VAT, CE certified to 2006/42/EC.

Twelve pads are the configuration for the largest and thinnest sheets, in steel, stainless, aluminium or polyethylene: each grip carries a fraction of the weight and the sheet does not deflect between one point and the next. The arms adjust to the format and the pads move onto solid areas when the sheet is perforated.

The dismountable structure weighs less than a fixed frame of the same size and passes through doors: the lifter is assembled next to the stack, works, and goes back to the warehouse in a few elements. It is the choice for construction sites, assembly at the customer's premises and workshops that handle large formats only in certain phases.

The vacuum is monitored by the vacuum gauge with reservoir and non-return valve, which maintains the grip if the power fails; the central eyebolt hooks onto a jib crane, overhead crane, hoist or mobile crane. Electric, pneumatic or battery power according to the system available.

Capacity, number of elements and spacing are defined on the customer's formats and thicknesses. For heavy, long sheets, over 2,500 kg or 4-6 metres, the solution is the telescopic beam, up to 8,000 kg in the catalogue and 15,000 kg to specification.

Typevacuum lifter for sheet metal with frame dismountable into elements
Pads12, adjustable on the arms
Uselarge-format thin sheets and plates, sites and assembly work
Power supplyelectric, pneumatic or battery, according to the system
Safetyvacuum reservoir, non-return valve, vacuum gauge
CertificationCE 2006/42/EC and EN 13155, capacity plate
€ 4.200 + VAT

Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.

Data sheets

Frequently asked questions

Dismountable 12-pad vacuum lifter for large-format sheets: the most common questions

It is sized on the customer's sheet format and thickness: twelve pads mainly serve to keep large, thin sheets flat rather than to reach high capacities. Tell us maximum format, thickness and material and we give you the rated capacity.
