Pneumatic clamp for kerbs, blocks and special loads

The pneumatic clamp opens and closes on command: a compressed-air cylinder moves the jaws and the operator decides when to grip and when to release, without relying on the weight of the load. For kerbs, blocks, bitumen slabs and special loads that must be picked up and placed precisely, built to measure on the workpiece. CE certified, list price 1,800 € + VAT.
Compared with the scissor clamp, the pneumatic clamp also grips light loads and releases them at height or in positions where setting down would not free the jaws: laying kerbs, stacking blocks, feeding machines.
Opening, clamping force and jaw lining are defined on the load; supply from the workshop compressed-air line or from a small compressor on the vehicle.
Used under overhead cranes, jib cranes and mini excavators with an auxiliary line; push-button control on the clamp or remote control.
Certified to 2006/42/EC with capacity plate and certificate.
| Operation | pneumatic, controlled opening and closing |
| Use | kerbs, blocks, bitumen, special loads |
| Rated capacity | on the load, on the plate |
| Build | made to measure |
| Power supply | compressed air |
| Certification | 2006/42/EC, marking and certificate |
Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.
Data sheets
Pneumatic clamp for kerbs, blocks and special loads: the most common questions
List price from 1,800 € + VAT; opening, capacity and controls define the price.
Yes: from the workshop air line or from a compressor on board the vehicle.
The circuit is designed with a check valve: the clamp stays closed until the opening command.
