25-tonne jib crane for boat hauling

25-tonne jib crane for boat hauling
Jib cranes for boat hauling

The 25-tonne jib crane for boat hauling is the largest in the price list: column on a foundation, electric 360° slewing on slewing ring, wire rope hoist with electric trolley and telescopic lifting beam to lift and set down the heaviest hulls in boatyards and ports. Built in Milan, painted for marine environments, list price 65,000 € + VAT; beyond that, custom-built up to 40 tonnes.

Twenty-five tonnes cover large motor yachts and sailing boats: the hull is taken with four slings on the lifting beam telescopic on all axes and rises level, controlled by radio remote control.

Column, jib and slewing ring are sized on the moments with the load at the jib tip; the concrete foundation and the anchor bolts follow our drawing, with a check of the quay ground.

For hulls over 25 tonnes the crane is custom-built up to 40 tonnes, with single or double jib; for long hulls the double-jib version keeps the slings at the right distance.

Paint for marine environments, electrical components for outdoor use; certified to 2006/42/EC with capacity plate and declaration of conformity, delivered assembled and tested.

Rated capacity25.000 kg
Rotationelectric, 360° on slewing ring
Liftingelectric wire rope hoist with electric trolley
Controlsradio remote control
Useboatyards, ports, heavy hulls
Certification2006/42/EC, capacity plate and declaration of conformity
€ 65.000 + VAT

Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.

Data sheets

Frequently asked questions

25-tonne jib crane for boat hauling: the most common questions

List price 65,000 € + VAT; outreach, height, foundation, hoist and lifting beam are confirmed in the quotation.
