Lifting beam for flanges and rings, custom-built

The lifting beam for flanges and rings lifts flanges, rings and gear rims from the holes of the piece: two dedicated attachments enter the holes, the lifting beam keeps the piece level and presents it to the lathe, the gear cutting machine or the assembly bench without slings that slip. Special version manufactured by Attollo, sized on the diameters, holes and weights of the customer's flanges. List price from 2,800 € + VAT.
The attachments are positioned on the hole diameter and the upper hook stays plumb over the centre: the flange rises horizontal, without swinging, and is set down on the machine in the correct orientation.
Slings on rings work poorly: they slip on the polished piece and hold it tilted. The dedicated lifting beam completes the cycle safely and without marking the machined surfaces.
It is the lifting beam for machine shops and manufacturers of flanges, rims and rings for the wind, petrochemical and marine sectors, with overhead crane or jib crane. Steel structure with primer and two coats of enamel, swivel hook and shackles as standard.
2006/42/EC certified with capacity plate and declaration of conformity; the diameter, hole spacing and maximum weight of the flanges are required.
| Grip | from the flange holes, two dedicated attachments |
| Rated capacity | on the maximum flange weight, on the plate |
| Diameters | defined on the customer's pieces |
| Build | custom-built, painted steel |
| Supply | swivel hook and shackles |
| Certification | 2006/42/EC, capacity plate and declaration of conformity |
Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.
Data sheets
Lifting beam for flanges and rings, custom-built: the most common questions
List price from 2,800 € + VAT; the price is confirmed on the diameter range and the weight of the flanges.
Yes, within the range defined at the time of order; the attachments are adjusted on the holes, with locked positions.
It is included: it allows the flange to be oriented during handling without twisting the hoist line of the crane.
