Certified 1,000 kg support trestle, A CA 1


The 1,000 kg support trestle is the size for medium steel fabrication: 1,500 mm top beam, 900 mm height, 700 mm base and 29 kg weight, in painted steel. Compared with the 500 kg model it has three hundred millimetres more top beam and twice the capacity with the same footprint; it is used in pairs for beams, frames and mechanical units awaiting assembly. List price 500 € + VAT.
The table on this page lists the whole A CA series: the 1,500 mm top beam is shared by the models from 1,000 to 5,000 kg, which differ in section sizes and weight (from 29 to 50 kg); from 7 tonnes the top beam goes to 2,000 mm and the base to 1,000 mm.
Tubular top beam closed with end caps, cross-braced uprights, plate feet that rest on the floor without anchoring; rust-proof primer and two coats of enamel. Support surface can be lined on request.
A pair supports 2,000 kg: sections, welded frames, rolled sheet metal and mechanical units at working height, in the workshop, in steel fabrication and on site. It is the same base as the trestles with roller or fork supports.
Supplied with capacity plate, serial number, manual and 2006/42/EC certificate.
| Model | A CA 1 |
| Rated capacity | 1,000 kg per trestle |
| Beam L | 1.500 mm |
| Height | 900 mm, base B 700 mm |
| Support base | 50 mm |
| Weight | 29 kg |
| Structure | painted steel, braced uprights |
| Certification | 2006/42/EC, capacity plate, serial number, manual and certificate |
Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.
Certified 1,000 kg support trestle, A CA 1 — models and capacities
| Type | L (mm) | H (mm) | B (mm) | Capacity (Kg) | Base (mm) | Weight (Kg) |
|---|---|---|---|---|---|---|
| A CA 0,5 | 1.200 | 900 | 700 | 500 | 50 | 26 |
| A CA 1 | 1.500 | 900 | 700 | 1.000 | 50 | 29 |
| A CA 2 | 1.500 | 900 | 700 | 2.000 | 50 | 32 |
| A CA 3 | 1.500 | 900 | 700 | 3.000 | 50 | 47 |
| A CA 5 | 1.500 | 900 | 700 | 5.000 | 50 | 50 |
| A CA 7 | 2.000 | 900 | 1.000 | 7.000 | 100 | 90 |
| A CA 10 | 2.000 | 900 | 1.000 | 10.000 | 100 | 122 |
| A CA 15 | 2.000 | 900 | 1.000 | 15.000 | 100 | 140 |
Technical data from the Attollo catalogues. Prices and custom configurations on request.
Data sheets
Certified 1,000 kg support trestle, A CA 1: the most common questions
List price 500 € + VAT per unit; it is used in pairs.
A 1,500 mm top beam instead of 1,200 and twice the capacity, with the same footprint and 3 kg more weight.
Yes: the 1,000 kg base is the one used for the custom trestles with roller or fork supports.
