Standard series aluminium gantry crane 3,000 kg (ASB)
ASB series aluminium gantry cranes: the universal range with spans up to 7 metres, capacity according to the beam and support configuration, and a complete ecosystem of accessories — winches, load trolleys, oversized wheels and stabilisers. It adapts to the job, not the other way round.
The ASB standard series raises capacity and stiffness over the LSB while keeping manual assembly: it is the most chosen compromise between the weight of the equipment and lifting capacity, with multi-position height adjustment.
It covers most recurring industrial lifts: die changes, moving motors and gearboxes, positioning machinery. CE 2006/42 certified, available in several heights and track widths.
| Capacity | up to 3,000 kg (supports A1 · B1 · C1 with a beam up to 4 m) |
| Beam length | 2 – 7 m (200 · 250 · 300 · 350 · 400 · 500 · 600 · 700 cm) |
| Beam weight | from 26.7 to 93.5 kg |
| Beam working range | from 77 to 577 cm |
| Supports | A1 · B1 · C1 · C2 |
| Working height | from 159.4 to 643.0 cm according to the support |
| Height adjustment | in 20 cm steps |
| Accessories | winches, trolleys, wheels, stabilisers |
| Standards | EN 13001 · EN 15011 |
List price, excluding VAT. Availability and delivery times confirmed the same day, together with the configuration that suits your load.
