Fork-mounted jib crane for forklift trucks

The fork-mounted jib crane slides onto the forks of the forklift truck and turns it into a mobile crane: the column with the slewing arm carries the hook or the hoist around the truck, and the load is lifted and set down without moving the machine. Built in Milan around the forks and the capacity of the truck, certified 2006/42/EC, list price 3,500 € + VAT.
Unlike the beam-type crane arm, which works only in front of the mast, the slewing arm serves an area around the truck: the forklift stops, the arm rotates, and the load is picked up and set down to the side. The manual chain hoist or direct lifting on the hook depends on the job.
The base slides onto the forks and is secured behind the heels, so the attachment stays fixed to the truck during the manoeuvre; capacity and outreach are sized on the residual capacity of the truck, which we check free of charge against the forklift's capacity plate.
It is the solution for workshops and warehouses with no overhead travelling crane that use the forklift for service lifts: motors, dies, crates, parts to be lowered into a machine. It is fitted and removed in a few minutes and the truck goes back to its forks.
Supplied with CE marking, capacity plate and declaration of conformity; special versions, hoist and gripping accessories are quoted together with the crane.
| Assembly | fork-mounted, secured behind the fork heels |
| Arm | slewing, outreach sized on the truck |
| Rated capacity | on the residual capacity of the truck, shown on the capacity plate |
| Lifting | hook or manual chain hoist, as preferred |
| Certification | 2006/42/EC, capacity plate and declaration of conformity |
Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.
Data sheets
Fork-mounted jib crane for forklift trucks: the most common questions
List price 3,500 € + VAT; hoist, outreach and special versions are confirmed in the quotation.
It depends on the truck: the rated capacity is sized on the residual capacity of the forklift at the chosen outreach, checked free of charge against the manufacturer's tables.
The beam-type crane arm is simpler and cheaper and works in front of the mast; the jib crane rotates and serves the area around the truck without moving it.
