Light overhead travelling crane on columns, single-girder up to 10 tonnes

Light overhead travelling crane on columns, single-girder up to 10 tonnes
Overhead cranes and suspended systems

The light overhead travelling crane on columns covers the working area without loading the factory building structure: its own columns carry the runway, the steel plate girder runs on top with motorised travel and the wire rope hoist serves the whole bay. Single-girder up to 10 tonnes and 25 metres span, double-girder up to 60 tonnes and 32 metres, designed and built by Attollo. List price from 8,000 € + VAT.

The top-running single-girder overhead crane reaches 10 tonnes with a span of up to 25 metres; the double-girder 60 tonnes and 32 metres, with more height below the hook. The low-headroom version makes the most of low factory buildings; girders with bolted joints travel in 40-foot open-top containers.

Overhead cranes use wire rope hoists and electric power supply lines: bridge travel, trolley travel and lifting from the pendant control or the radio remote control, with slow speeds for positioning.

Its own columns make the overhead crane independent of the factory building: it is installed where the roof cannot take the load or in rented buildings, and it can be dismantled and reassembled elsewhere.

Design based on the factory building and duty cycles, assembly and testing; certified to 2006/42/EC with declaration of conformity, manual and file for periodic inspections.

Typetop-running single-girder overhead crane on its own columns
Rated capacityup to 10 t (double-girder up to 60 t)
Spanup to 25 m (double-girder up to 32 m)
Travelmotorised
Liftingelectric wire rope hoist
Controlspendant control or radio remote control
Certification2006/42/EC, capacity plate and declaration of conformity
€ 8.000 + VAT

Custom-built: every piece of equipment is custom-built and certified to CE 2006/42. Request a quotation for your exact configuration and capacity.

Data sheets

Frequently asked questions

Light overhead travelling crane on columns, single-girder up to 10 tonnes: the most common questions

List price from 8,000 € + VAT; the final price follows the design based on capacity, span, height and runway length.
